Pulse Jet Bag Filters
Authentic ASME & TEMA compliant process engineering machinery custom-fabricated in our Vadodara plant.
Equipment Portfolio
Showing 5 registered equipment models in this category.
₹ 4.95 Lakh / PiecePulse Jet Bag Filter
High-efficiency pulse-jet dry dust collector designed to capture airborne particulates and return clean air back to industrial workspaces.
| Capacity Volume | 8,000 CFM |
| Filter Bag Material | Polyester Needle Felt (550 gsm) |
| Number of Cages | 48 bags / cages |
₹ 4.95 Lakh / PieceAutomatic MS Bag Filter
Fully automated Mild Steel pulse-jet baghouse collector equipped with an integrated PLC timer panel, hopper, and dust release airlock.
| Capacity Range | 5,000 CFM |
| Shell Material | Mild Steel plate (IS 2062) |
| Cleaning Timer | Adjustable solid-state sequential timer |
₹ 4.95 Lakh / PieceBag Filter Housing
Heavy structural steel baghouse enclosure housing filter bag bundles, engineered to withstand high wind forces and negative draft pressures.
| Flow Capacity Limit | Up to 35,000 CFM |
| Plenum door type | Swing door top-removal clean plenum |
| Weld inspections | Liquid penetrant / Vacuum testing |
₹ 4.95 Lakh / PieceBoiler Bag Filter
Specialized high-temperature baghouse filter designed to capture hot fly ash from solid fuel (wood, coal, biomass) fired boiler exhausts.
| Capacity Range | 6,000 CFM to 12,000 CFM |
| Bag Material | Nomex (High Temperature) /Ryton |
| Design Temperature | Up to 220°C |
₹ 4.95 Lakh / PieceAir pollution bag filter
Industrial bag filter system engineered for general air pollution control, powder extraction, and dry solid recovery venting.
| Filter Area | 85 sq. meters |
| Bag Length | 2,000 mm |
| Blower Motor Power | 7.5 HP |
